Tracks: 18 + 2 Master Tracks, V-Tracks: 320 (16 V-Tracks per each Track)
Sample Rate 44.1 kHz
Recording Mode:
Linear 24 bits (M24), Linear 16 bits (M16), CD Writing (CDR) *Master tracks only
Maximum Simultaneous Recording/Playback Tracks
8 tr. Rec / 18 tr. Play (M16), 8 tr. Rec / 12 tr. Play (M24) *Depending on the organization of the song data, the disk drive performance, etc., the number of tracks that can be simultaneously recorded or played back may be limited.
Internal Hard Disk Drive Capacity: 40 GBRecording Time (10GB Partition, calculated for 1 track)1,340 min. (M24), 2,020 min. (M16) *The above-listed recording times are approximate. Times may varies slightly depending on the specifications of the disk drive and the number of songs that were created. *Maximum recording time of VS-2000CD is approximately 4 times of above recording time. (approximately 10 GB x 4 partitions)
Frequency Response: 20 Hz—20 kHz(+0dB/-2dB)
Projects: 200 projects in each partition
Marker :1000 per project
Locator: 96 (16 x 6 banks) per project
Scene: 96 (16 x 6 banks) per project
Undo/Redo
999 Undo / 1 Redo
Nominal Input Level (variable)
Input 1—8:-50— +14 dBu (maximum +26 dBu: balanced, maximum +20 dBu: unbalanced), Guitar (Hi-Z): -50— +14 dBu (maximum +20 dBu)
Input 1—8: 32 k ohm (balanced), Guitar (Hi-Z): 1 M ohm
Nominal Output Level
Master Out: +4dBu (balanced), AUX (L, R): 0 dBu (unbalanced), Monitor Out: 0 dBu (unbalanced)
Output Impedance
Master Out: 600 ohm, AUX (L, R): 300 Ohm, Monitor Out: 300 ohm, Phones: 22 ohm
Recommended Load Impedance
Master Out: 10 k ohm or greater, AUX (L, R): 10 k ohm or greater, Monitor Out: 10 k ohm or greater, Phones: 32 ohm
Residual Noise Level (INPUT SENS: LINE, IHF-A, typ.)
Master Out: -86 dBu or less, AUX: -86 dBu or less, Monitor Out: -86 dBu or less
EQ
4-band (2 shelving + 2 peaking)
Dynamics Processor
Compressor, Expander
Effects
Maximum 6 stereo (One pre-installed + 2 more optional Effect Expansion Boards)
Display
320 x 240 dots Graphic LCD (with backlit)
Digital I/O: Coaxial (conforms to IEC60958), MIDI: 5-pin DIN, USB: USB2.0 Mass Storage
Hard Disk Drive 3.5-inch, 40 GB
CD-RW Drive
Reading Speed: 24x (max.), Recording Speed:Supports 4x speed writing (CD-R), Supports 4x speed rewriting (CD-RW)
Connectors
MIDI Connectors (5-pin DIN type), USB Connector, Input Jack 1—8 (XLR type, phantom power), Input Jack 1—8 (1/4 inch TRS phone type), Guitar (Hi-Z) Jack (1/4 inch phone type), Digital In Connectors (Coaxial type), Digital Out Connectors (Coaxial type), Foot Switch Jack (1/4 inch phone type), Master Out Jack L/R (1/4 inch TRS phone type), Monitor Out Jack L/R (RCA phono type), AUX Send Jack L/R (RCA phono type), Headphones Jack (Stereo 1/4 inch phone type)
Power Supply DC 12 V (AC Adaptor)
Current Draw 3.6A
Width 466 mm - 18-3/8 inches
Depth 369 mm - 14-9/16 inches
Height 118 mm - 4-11/16 inches
Weight 6.7 kg - 14 lbs. 13 oz
Accessorios
Owner's Manual, Appendices, Mixer Block diagram, Application Software CD (VS-2000 Wave Converter), Short Cut Seal, Power Cord, AC Adaptor (PSB-3U)
24-bit Effect Expansion Boards: VS8F-2, VS8F-3, Foot Switch: FS-5U (BOSS), Pedal Switch: DP-2
